62 ton bollard pull FiFi 1 tug
Driven by a pair of variable pitch Azimuth Stern Drives combined with a Brunvoll bow thruster makes this vessel very maneuverable, an ideal vessel for working in close quarter situations in poor weather.
General
Vessel type: FiFi 1 tug
IMO number: 9085209
Classification: DNV
Call sign: EI-SG-9
Flag: Ireland
Port of registry: Skibbereen
Dimensions & Tonnage
Length overall: 35.11 m
Beam overall: 10.8 m
Draught: 4.8 m
Gross tonnage: 546 GT
Net tonnage: 163 NT
Propulsion & Performance
Main engines: 2 x Wartsila Winchman, 5,000 hp
Propulsion: 2 x Ulstein Liaaen Compass ASD
Bow thruster: 1 x Brunvoll, 300 hp
Light speed: 14 knots
Bollard pull: 62 t
Firefighting & Pollution Response
FiFi make: FFS
FiFi type: Scanpump
FiFi capacity: 2,500 m³/hr
Ship/shore supply: 2,600 m³/hr
Skimmer: Komara 20
Oil boom: 300 m NOFI 600S
Deck & Working Equipment
Aft towing winch: 225 t Karm winch with 800 m x 57 mm wire
Forward towing winch: 225 t Karm split winch with 1 x 140 m x 80 mm Superline fibre rope and 1 x 500 m x 48 mm wire
Tugger winch: Karm, 1 x 10 t
Towing pins: 300 t rated
Karmoy fork: 120 t rated
Crane: Effer, 40 tonne-metre
RIB / rescue boat: Narwhal SV420 with 25 hp outboard
Accommodation & Crew Facilities
Cabins: 3 x single cabins and 3 x double cabins
Facilities: Galley, mess room, office, gym and laundry room
